Rigid Pavement Design for Juneau's Glacial Terrain

Juneau's pavement problems start below the surface. The city sits on a patchwork of glacial till, marine clay, and peat deposits left by the Mendenhall Glacier. The water table sits high across much of the Mendenhall Valley, often within three feet of grade. A rigid pavement here has to handle saturated subgrades, freeze-thaw cycles, and occasional seismic loads from the Fairweather-Queen Charlotte fault system. We run the subgrade investigation first. That means coring through fill, logging the clay seams, and pulling undisturbed Shelby tube samples. The concrete slab design follows from what we find down there. For city projects near Egan Drive or residential streets in Douglas, we pair the pavement analysis with a CBR road investigation when the subbase includes granular borrow, and we look at slope stability where road cuts climb the steep terrain above Gastineau Channel.

In Juneau, the frost depth reaches 60 inches in exposed cuts. If the base course isn't free-draining, the slab curls and the joints pump in March.

How we work

Our field crew runs a heavy dynamic cone penetrometer on the grade and a nuclear density gauge on the compacted subbase. The DCP gives us a continuous stiffness profile down to 36 inches. In Juneau's glacial till, the blow count can jump from 4 to 20 in less than six inches. That matters for joint design. We also pull cores from existing concrete pavements to check for alkali-silica reaction, a real concern with the local aggregates sourced from the Gastineau Channel alluvium. The lab runs compressive strength on cylinders per ASTM C39 and flexural strength on beams per ASTM C78. We check the modulus of rupture because it directly feeds the Westergaard equations for slab thickness. Freeze-thaw durability testing follows ASTM C666, Procedure A. Every mix design we review includes an air-void analysis. Without proper entrained air, a Juneau slab spalls in two winters. We also run the gradation on the base aggregate per ASTM D448, because an open-graded base under a rigid pavement drains the meltwater before it can pump fines at the joints.

Site-specific factors

We see the same failure in Juneau over and over: a well-poured slab that cracks diagonally from the corner within the first year. The cause is almost always a saturated subgrade that froze before the base course drained. The water expands, the slab lifts, and the corner loses support. When the truck axle hits it, the concrete snaps. Another common problem is joint spalling from a mix that lacked air entrainment. The top quarter-inch of the joint face scales off after one winter of salt and freeze-thaw. Repairs on a rigid pavement are expensive and visible. Cutting out a failed panel and doweling in a replacement shuts down a lane for days. We'd rather get the subgrade and the mix right the first time. The extra day of field testing pays for itself within two years of service.

Technical data

Parameter	Typical value
Slab thickness design method	PCA method / Westergaard analysis
Concrete compressive strength (f'c)	4,000 psi min. for arterial roads
Flexural strength (modulus of rupture)	550-650 psi at 28 days
Subgrade modulus (k-value)	Determined via 30-inch plate load test or CBR correlation
Joint load transfer	Dowelled joints for heavy truck routes, aggregate interlock for local streets
Frost protection depth (per IBC Table 1809.5)	60 inches below finished grade in exposed areas
Base course	ASTM No. 57 open-graded crushed stone, 6-inch minimum thickness

Associated technical services

Subgrade modulus (k-value) testing

Plate load test on the prepared subgrade or base course, per ASTM D1196. We run a 30-inch plate to capture the stiffness the slab will actually feel.

Concrete mix design review

Aggregate gradation, alkali-silica reactivity screening, and air-void analysis. Every mix gets a freeze-thaw durability check before it goes to the batch plant.

Pavement joint layout and detailing

We size the panels, specify dowel diameter and spacing, and locate the joints to match the traffic loads and subgrade conditions across the site.

Construction QA/QC testing

Slump, air content, and cylinder casting on-site. We check the base compaction and grade before the pour starts. No slab goes down without a documented subgrade.

Quick answers

How much does a rigid pavement design cost for a Juneau project?

The fee for a rigid pavement design package, including subgrade investigation, k-value testing, and mix review, runs between US$1,850 and US$6,530 depending on the project length and the number of borings required.

What frost depth do you design for in Juneau?

We follow IBC Table 1809.5, which specifies a frost penetration depth of 60 inches for Southeast Alaska. The base course thickness and subdrainage system are designed to keep water out of the frost zone.

Do you test for alkali-silica reactivity in local aggregates?

Yes. We run the accelerated mortar bar test per ASTM C1260 on aggregates sourced from Juneau area pits. Several local sources have shown reactive silica content, so we specify supplementary cementitious materials when needed.

What joint load transfer system do you recommend for bus routes?

For arterial roads with bus or truck traffic, we specify dowelled contraction joints with epoxy-coated bars. The dowel diameter and spacing follow PCA guidelines based on the slab thickness and traffic index.

Can you test an existing rigid pavement to determine the cause of cracking?

We can. We pull cores to check compressive strength, measure the air-void system, and run a petrographic examination per ASTM C856. We also cut a test pit through the slab to inspect the base and subgrade condition below the failed panel.
